Adjust the power level and frequency: If the Tramp Rx pin cable on VTx is connected with FC, then the button doesn’t work.
| Name | Reaper Infinity |
| Input Voltage | 9~36V |
| Output Voltage | 5V |
| Channels | 40CH |
| Power | 50mW/500mW/1000mW/2500mW/5000mW, red light flash 1/2/3/4/5 times correspondingly |
| Pit | Double click to enter |
| Weight | 58g |
| Mounting Hole | 20*20mm M2 |
| Size | 72*41*17mm |
| Connector | SMA |
| Consumption | 9V/3A; 36V/0.8A |
| Band | CH1 | CH2 | CH3 | CH4 | CH5 | CH6 | CH7 | CH8 |
| Band A | 5865 | 5845 | 5825 | 5805 | 5785 | 5765 | 5745 | 5725 |
| Band B | 5733 | 5752 | 5771 | 5790 | 5809 | 5828 | 5847 | 5866 |
| Band E | 5705 | 5685 | 5665 | 5645 | 5885 | 5905 | 5925 | 5945 |
| Band F | 5740 | 5760 | 5780 | 5800 | 5820 | 5840 | 5860 | 5880 |
| Band R | 5658 | 5695 | 5732 | 5769 | 5806 | 5843 | 5880 | 5917 |
Unlock/Lock the illeague frequencies and power levels:
Long press the “KEY” button until the Red LED (PWR) isconstant on, then off, when it is on again, release the button,unlock/lock the illegal frequencies and power levels, flashedRed LED is unlocked, constant Red LED is locked.
PIT On/Off:
Double-click the “KEY” button to turn on/off thePIT Mode. Red LED (PWR) off, PIT mode on; Red LED (PWR) on,PIT mode off.
