Lead Time – 30 Days
PRODUCT SPECIFICATIONS
| Kv (Motor Velocity Constant) | 180 RPM/V |
| Kt (Motor Torque Constant) | 0.068 Nm/A @ 5291 rpm |
| Maximum Continuous Current* | 47 A (180 s) |
| Maximum Continuous Power* | 2209 W (180 s) |
| Power Denisity |
3.53 W/g (Rated), 6.863 W/g (Maximum)
|
| Voltage Range | 44V to 52V (12S LiHV) |
| Io (@48V) | 2.5 A |
| Inductance per phase (Winding Inductance) | 0.046mH ( ≃0.03) |
| Rph (Wind Resistance per phase) | 0.05Ω ( ≃0.03) |
| Stator Poles | 24S(24S28P) |
| Magnetic Poles | 28P(24S28P) |
| Bearings | Triple, 619/6-2Z |
| Stick Out Shaft Diameter | ø6mm |
| Motor Diameter | ø69.5mm |
| Motor Length | 40mm |
| Motor Weight | 425g |
| Mount Pattern @ 90 deg | 4XM4 ↧8mm ø30mm |
| Propeller Blade Size* | Max Propller Size – 26inch |
| Propeller Mount Pattern | 6XM3 ↧5.5mm ø54mm 4XM3 ↧3.8mm ø12mm , 4XM3 ↧6mm ø18mm, 4XM3 ↧6mm ø20mm |
| Propeller | Voltage | PWM | RPM | Thrust (g) | Torque (N*m) | Current (A) | Electrical Power | Efficiency | Temperature (Celcius) | Throttle % |
| 22*6.6 CF Fixed wing | 50 | 1220 | 1492 | 381 | 0.1 | 2.08 | 104 | 3.7 | 61 | 15 |
| 50 | 1300 | 2291 | 920 | 0.23 | 3.17 | 159 | 5.8 | 61 | 25 | |
| 49.8 | 1420 | 3402 | 2117 | 0.53 | 6.4 | 319 | 6.6 | 61 | 40 | |
| 49.5 | 1540 | 4514 | 3940 | 0.97 | 12.87 | 637 | 6.2 | 61 | 55 | |
| 49.2 | 1620 | 5141 | 5174 | 1.28 | 18.55 | 913 | 5.7 | 60 | 65 | |
| 48.8 | 1700 | 5680 | 6632 | 1.62 | 25.58 | 1248 | 5.3 | 59 | 75 | |
| 48.1 | 1820 | 6584 | 8737 | 2.14 | 39.57 | 1903 | 4.6 | 57 | 90 | |
| 47.9 | 1860 | 6834 | 9425 | 2.34 | 44.69 | 2141 | 4.4 | 55 | 95 | |
| 47.6 | 1900 | 7081 | 10131 | 2.55 | 50.23 | 2391 | 4.2 | 54 | 100 |
| Propeller | Voltage | PWM | RPM | Thrust (g) | Torque (N*m) | Current (A) | Electrical Power | Efficiency | Temperature (celsius) |
| 24*80 Foldble Propeller | 50.3 | 1200 | 2116 | 2146 | 0.61 | 2.8 | 140.8 | 15.3 | 35.5 |
| 50.1 | 1300 | 3024 | 4338 | 1.3 | 7.4 | 370.7 | 11.7 | 35.5 | |
| 49.6 | 1400 | 3898 | 6973 | 2.06 | 15.9 | 788.6 | 8.9 | 36.4 | |
| 49 | 1500 | 4586 | 8815 | 2.6 | 26.2 | 1,283.80 | 6.9 | 37.7 | |
| 48.2 | 1600 | 5141 | 10805 | 3.14 | 39 | 1,879.80 | 5.7 | 40.5 | |
| 47.2 | 1700 | 5674 | 12609 | 3.63 | 55.2 | 2,605.40 | 4.8 | 44.7 | |
| 46.1 | 1800 | 6083 | 13842 | 3.98 | 72.9 | 3,360.70 | 4.1 | 50.1 | |
| 45.5 | 1900-2000 | 6149 | 14000 | 3.83 | 78.3 | 3,562.70 | 3.7 | 56.4 |
Performance Data
Thrust Bench data with various propellers
Certifications
Standard Tests and Certifications
CAD FILES
2D / 3D CAD MODEL
